190LM/W Ultra High Lumen Output Y Series LED High Bay Light For Industrial

Brand Name:	Goldenlux
Model Number:	Y-Series
MOQ:	1
Price:	$28-999
Packaging Details:	Cartons
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE, ROHS

Dimension:

L400*W400*H190mm

Watt:

100W-240W

Cover:

Glass

Light Source:

Lumileds

Luminous Efficiency:

150-190lm/w

Driver Cert:

CE ROHS UL

Installation:

Loop Hanging, Bracket Mounting

Lamp Efficiency:

Voltage:

AC120-277V | 50/60Hz

Diffuser:

Tempered Glass

Ra>80

IP Rating:

Beam Angle:

60°/ 90°/ 120°

LED Type:

SMD2835

Operating Temperature Range:

3000K/ 4000K/ 5000K/ 5700K/ 6500K

Supply Ability:

Thousands Pieces/Month

Highlight:

100w led bay light

240w led bay light

100w led high bay light

Product Description

Up To 190LM/W

Y-Series is cost-effective High Power Light source, combined with High Performance, to provide 190 LM/W of ultra-high Lumen Output version. A durable, Highly Effective Industrial LED Luminarie offers wide range wattage from 100W-240W. The luminaire housing is manufactured in high purity die-cast aluminium with black polyester powder coated paint finish. Supplied with external driver and pre-assembled cable.

A Variety Of Power Supply Options

Output wattage covers 100W-240W, Goldenlux try it best to become the leader of UFO High Bay Lighting design and make the efficiency of LED High Bay Lighting much more better. Simultaneously, we provided 1-10V or DALI2 dimming functions to allow customers to use smart Lighting control for desired effect. Therefore, Goldenlux has comprehensive Lighting Solutions for all kinds of application.

Up To 240W

Warranty 5 Years

Mounting Options

Eye-Bolt, Or Adjustable Bracket For Surface Mounting

Motion Sensor Available

Applications like warehouses, distribution centers, production facilities and other Industrial Spaces with occupancy less than 50% and High Ceilings(15–45 ft) are ideal environment for sensors. It helps saving-energy costs by delivering Light only where you need it, when you need it.

Plug & Play Sensor

Integrated motion sensor can be programmed to increase energy-saving, customized detection range daylight, threshold, timer, and dimming settings.

Excellent Heat Dissipation

The well-proportioned ribs lay the foundation for the High-quality heat dissipation of the product.

Anti-Glare Reflector

Use this reflector to reduce glare from your 100-150-200 Watt UFO LED High-Bay Light and to create a traditional High-bay look. The reflector installs around the fixture's lens and comes with 4 screws to secure it in place.

Y-Series Product Technical Specifications

Series	Y-Series
Power	100W, 150W, 200W, 240W
Efficacy	150LM/W, 170LM/W, 190LM/W
Input Voltage	120-277VAC, 50/60Hz
Power Factor	＞0.9
Surge Protector	6KV Line-Line, 6KV Line-Earth
Control	1-10V, DALI2(Optional)
IP Rating	IP65
IK Rating	IK09
CCT	3000K, 4000K, 5000K, 5700K, 6500K
CRI	CRI＞70 Standard CRI＞80 Optional
Operating Temperature	-30°C — +45°C
Beam Angle	60, 90, 120 Angle
Mounting Option	Loop Hanging, Bracket Mounting
Reflector	Aluminum Reflector/ PC Reflector
Warranty	5 Years Warranty
